5 1/4" speakers with neo-sym motor

  • 6
    Participant count
  • Participant list

brmcm15
10+ year member

Oh lawdy!




at partsexpress for $28.45

going to buy some to put in factory spot so i can sell the car.

look pretty nice to me

Dayton Audio's compact aluminum cone drivers demonstrate the latest advances in high-excursion design processes. An efficient, low-distortion Neo-Sym motor is combined with a rigid yet lightweight aluminum diaphragm, yielding impressive high-impact audio reproduction. Perfect for single point-source applications, or combined in multiples and line arrays. Specifications: *Power handling: 40 watts RMS/80 watts max *VCdia: 1" *Le: 0.72 mH *Impedance: 4 ohms *Re: 3.7 ohms *Frequency range: 54-8,000 Hz *Fs: 54 Hz *SPL: 85.3 dB 1W/1m *Vas: 0.36 cu. ft. *Qms: 6.59 *Qes: 0.74 *Qts: 0.66 *Xmax: 4 mm *Dimensions: A: 5-1/2", B: 4-3/4", D: 2-1/2".

* Extended-range 54 Hz to 8 kHz performance

* Rubber-edged aluminum alloy cone

* Large excursion capability—4 mm Xmax, 20 mm peak

* Self-shielded Neo-Sym motor structure

* 1" 4-layer underhung voice coil with polyimide former

* 40 watts RMS power handling


they sound pretty good, but i dont have my tweeters(PG RSD's) in cause i lost them somewhere //content.invisioncic.com/y282845/emoticons/crap.gif.7f4dd41e3e9b23fbd170a1ee6f65cecc.gif i have to buy new ones.

but man do these things move!!! ill try and get some vids of them up tomarrow. But overall totally worth what i paid for
